LJ12A3-4-Z/BX 3 wire inductive proximity sensor introduction:

LJ12A3-4-Z/BX 3 wire inductive proximity sensor is also called LM12 series sensor, is a M12 plug-in type proximity switch,
Threaded copper housings, with a clear LED status indicator,
It is used to detect metal objects, it is inductive approach switch with 3 or 4 cores aviation plug,
This LJ12A3-4-Z/BX inductive proximity switch distance can be 2mm(shielded) or 4mm(unshieled), the outputs can be PNP, NPN, NO, NC or NO+NC.
If you choose NPN output, it can be used with JDM11-5H totalizing counter to count the metallic objects numbers.


Flush	Detection distance			2mm
	DC6-36V	NPN	NO	LJ12A3-2-Z/BX(LM12-3002NAT)
			NC	LJ12A3-2-Z/AX(LM12-3002NBT)
			NO+NC	LJ12A3-2-Z/CX(LM12-3002NCT)
		PNP	NO	LJ12A3-2-Z/BY(LM12-3002PAT)
			NC	LJ12A3-2-Z/AY(LM12-3002PBT)
			NO+NC	LJ12A3-2-Z/CY(LM12-3002PCT)
		two wire system	NO	LJ12A3-2-Z/EX(LM12-3002LAT)
			NC	LJ12A3-2-Z/DX(LM12-3002LBT)
	AC90-250V	Controllablel silicon	NO	LM12-2002AT
			NC	LM12-2002BT
			NO+NC
		Relay output
Non-flush	Detection distance			4mm
	DC6-36V	NPN	NO	LJ12A3-4-Z/BX(LM12-3004NAT)
			NC	LJ12A3-4-Z/AX(LM12-3004NBT)
			NO+NC	LJ12A3-4-Z/CX(LM12-3004NCT)
		PNP	NO	LJ12A3-4-Z/BY(LM12-3004PAT)
			NC	LJ12A3-4-Z/AY(LM12-3004PBT)
			NO+NC	LJ12A3-4-Z/CY(LM12-3004PCT)
		two wire system	NO	LJ12A3-4-Z/EX(LM12-3004LAT)
			NC	LJ12A3-4-Z/DX(LM12-3004LBT)
	AC90-250V	Controllablel silicon	NO	LM12-2004AT
			NC	LM12-2004BT
			NO+NC
		Relay output
Control output		DC		200mA
		SCR/Relay		300mA
Output voltage drop DC/AC				DC<2VDC(Two wire system) <3.9V AC<10V
Consumption current				DC<15mA AC<10mA
Standard detected object				15×15x1(A3 iron)
Repeated precision				0.01
DC/AC Response frequency				400Hz/25Hz
Working environment temperature				-25℃~65℃
Insulation resistance				50MΩ
Shell material				Metal
Protection grade				IEC standard IP 67
Alternative model				E2E-X5M
