Introduction:
-
- The H3Y-2 is a miniature power-on delay time relay, that is, when the power is connected to the load through this relay, the load will not be powered on immediately, but will turn on after a set time.
- The on delay time range can be one of 0-5 seconds, 0-3 seconds, 0-5 seconds, 0-30 seconds, 0-60 seconds, 0-3 minutes, 0-5 minutes, 0-10 minutes, 0-30 minutes, 0-60 minutes.
- The delay time can be set by a knob, easy to operate and simple to use.
- The overall size of the H3Y-2 time relay product is only 28*22*83mm(with the PYF08A-E socket), and its compact size can save more space.
- H3Y-2 timer has two delay contacts(DPDT), contact capacity is 5 amps@220VAC. If you need 4 contacts that are available for us as well, the model will be H3Y-4.
- The application of this timer relay can be delayed motor start, lighting control, HVAC system and other scenarios that require delayed start.
- Want to get H3Y-2 pricing or technical support from us, the time delay relay manufacturer? Fill out the form below to contact us today!
Specifications:
| Model | H3Y-2 |
| Working voltage | 36, 110, 220, 380VAC, 50/60 Hz; 12, 24, 48,110VDC |
| Contact capacity | H3Y-2: 5A@250Vac/28Vdc |
| Tolerance | -15%~10% at AC voltage and -10%~10% at DC voltage |
| Power consumption | Max.1.8W |
| Setting method | Knob |
| Indication method | LED indicator |
| Repeat accuracy | ±1% |
| Setting error | ±10%±0.05 sec |
| Mounting | DIN rail |
| Termination | H3Y-2: 8 pins |
| Mechanical life | 1x10^7 |
| Electrical life | 5x10^5 |
| Operating temperature | -10 to 50 ℃ |
| Operating humidity | 35-85% RH, non-condensing |
