CJX2 Contactor

Introduction:


Model	CJX2-09	CJX2-12	CJX2-18	CJX2-25	CJX2-32	CJX2-40	CJX2-50	CJX2-65	CJX2-80	CJX2-95
Same model	LC1-D09	LC1-D12	LC1-D18	LC1-D25	LC1-D32	LC1-D40	LC1-D50	LC1-D65	LC1-D80	LC1-D95
Rated current (AC-3) (A)@380V	9	12	18	25	32	40	50	65	80	95
Rated current (AC-3) (A)@660V	6.6	8.9	12	18	21	34	39	42	49	55
Rated thermal current (A)	20	20	32	40	50	60	80	80	80	125
Maximum power (KW)@220V	2.2	3	4	5.5	7.5	11	15	18.5	22	25
Maximum power (KW)@380V	4	5.5	7.5	11	15	18.5	22	30	37	45
Maximum power (KW)@660V	5.5	7.5	9	15	18.5	30	33	37	45	55
Mechanical life 10^4(ops)	1000	1000	1000	1000	800	800	800	800	600	600
AC3 electrical life 10^4(ops)	100	100	100	100	80	80	60	60	60	60
Maximum AC3 operations for 1 hour	1200	1200	1200	1200	600	600	600	600	600	600
AC4 electrical life 10^4(ops)	20	20	20	20	20	15	15	15	10	10
Maximum AC4 operations for 1 hour	300	300	300	300	300	300	300	300	300	300
Pick up (VA)	70	70	70	110	110	220	220	220	220	220
Sealed (VA)	8	8	8	11	11	20	20	20	20	20
Matched fuse	NT00-20	NT00-20	NT00-32	NT00-40	NT00-50	NT00-63	NT00-80	NT00-80	NT00-100	NT00-125
Cabling capacity-1 flexible wire size (mm2)	2.5	2.5	4	4	6	10	16	25	50	50
Cabling capacity-1 solid or stranded wire size (mm2)	4	4	6	6	10	6	25	25	50	50
Cabling capacity-2 flexible wire size (mm2)	2.5	2.5	4	4	6	10	16	25	25	25
Cabling capacity-2 solid or stranded wire size (mm2)	4	4	6	6	10	-	-
