Sensores de proximidad

  • Proximity sensor manufacturer in China
  • Good price&high quality
  • OEM&ODM available
  • Two-year extended warranty
Solicitar presupuesto
Download catalog
Lorentzzi proximity sensor-1

Nuestros productos

Lorentzzi offers a wide range of proximity sensors for industrial use. Our products include inductive proximity sensors, capacitive proximity sensors, photoelectric sensors and safety light curtains. All sensors are manufactured in accordance with strict European CE and RoHS standards.

  ¿No encuentra el producto que necesita? Haga clic en el botón para ponerse en contacto con nosotros.

Póngase en contacto con nosotros

¿Por qué elegirnos como proveedor?

proveedor chino

Nuestra fábrica está situada en el centro neurálgico de los electrodomésticos de bajo voltaje de China. Nuestros productos ofrecen una calidad superior y precios competitivos.

Amplia gama de productos

Lorentzzi can supply a full range of good quality proximity sensors, we ensure the sensors provided by us have excellent quality and 2 years warranty.

Entrega rápida

We always keep sensors stock at a reasonable level to meet customers' urgent orders. We believe that helping customers save time also helps them save money.

Aplicaciones de los sensores de proximidad

Proximity sensor used in automated production line

Automated production line

Proximity sensor used in level detection

Material level detection

Proximity sensor used in printing industry

Industria gráfica

Proximity sensor used in logistic sorting system

Logistic sorting system

Proximity sensor used in automatic door

Automatic door

Automatic lighting control

Preguntas más frecuentes

Have you ever noticed that the screen lights up automatically when a call comes in? When you answer the call and hold the phone close to your ear, the screen turns off automatically.

Why does this happen? Because there is a proximity sensor inside the phone that controls everything. This sensor automatically turns off the screen when the phone is close to your cheek during a call to prevent accidental touches and save battery life.

In the following chapters, we will explain the proximity sensor from different angles. Are you ready to learn?

¿Qué es un sensor de proximidad?

A proximity sensor is a device that detects the presence or absence of objects without physical contact. It operates by emitting signals such as sound, light, electric fields, or magnetic fields and analyzing the reflected or disturbed signals to determine if an object is within its sensing range.

While the functionality of a proximity sensor is similar to that of a limit switch, its non-contact operation makes it a suitable alternative in applications where contact-based sensing is impractical or undesirable.

Types of proximity sensors

According to different working principles, proximity sensors can be mainly divided into 5 types: ultrasonic sensors, sensores fotoeléctricos, inductive sensors, capacitive sensors and hall sensors. At Lorentzzi you can find all of these sensors in better quality.

Buy proximity sensor

For more details of these 5 types of proximity sensors, you can refer to our article: Tipos de sensores de proximidad: La explicación más completa.

Working principle of proximity sensors

Different proximity sensors have different working principles, you can check the following content for more information.

Ultrasonic sensors use the emitted and received ultrasonic waves to detect objects, and ultrasonic sensors can calculate the distance of objects by measuring the propagation time and frequency changes of ultrasonic waves.

There are three types of photoelectric sensors, namely diffuse photoelectric sensors, retro-reflective photoelectric sensor and through-beam photoelectric sensor. You can learn their working principles by reading this article: Tipos de barreras fotoeléctricas al descubierto: Su guía definitiva

Inductive and capacitive proximity sensors work completely differently, you can refer to our articles: Capacitive vs. Inductive Proximity Sensors: 5 Things You Need to Know y Cómo funcionan los sensores de proximidad capacitivos: La guía definitiva para más información.

The Hall sensor determines the proximity of an object by detecting changes in the magnetic field. When a magnetic object approaches, the magnetic sensitive element (such as the Hall element) inside the sensor detects the change in the magnetic field, thereby triggering a signal.

Choosing the right proximity sensor

When selecting the right Lorentzzi brand proximity sensor, the below 6 key factors should be considered:

  1. Type of Sensor:
    As previously discussed, proximity sensors come in various types, including ultrasonic, photoelectric, inductive, capacitive, and hall sensors. The choice depends on your specific application requirements.
  2. Shape:
    Proximity sensors are available in a variety of shapes, such as cylindrical, square, fork, and hole. Please choose the shape that best suits your installation needs.
  3. Working Voltage:
    Proximity sensors typically operate on either DC (6–36V) or AC (90–250V) voltage. DC sensors usually have three wires, while AC sensors typically have two wires.
  4. Detection Distance:
    The detection range of proximity sensors varies from as little as 1 mm to up to 10 meters, depending on the type and application.
  5. Output Type: The sensor has 2 types of outputs, including transistor and relay outputs. Transistor outputs include PNP or NPN outputs, and relays are similar to voltage-free switches. Transistor outputs have lower load capacity than relay outputs, but have faster response times. For more differences, refer to this article: Transistor Vs Salida De Relé En El Sensor De Proximidad: ¿Cuáles son las diferencias?
  6. Cable Length:
    Lorentzzi brand proximity sensor standard cable lengths for proximity sensors are typically 2 meters, our sensor cable length can be customized.

Proximity sensor wiring diagrams

Proximity sensor wiring diagrams can be categorized into three types based on output configuration: 2 wires, 3 wires and 4 wires, you can see the below wiring diagram for these three types:

Lorentzzi inductive proximity sensor wiring diagram
Need our support?

Preguntas frecuentes

Can proximity sensors detect humans?

Yes, photoelectric sensors and ultrasonic sensors can detect human bodies. They are commonly used in automatic door systems, security systems, and smartphones.

How far can a proximity sensor detect?

The detection range of a proximity sensor depends on its type. For example, photoelectric and ultrasonic sensors can have a detection range of tens of meters, while inductive, capacitive or hall sensors usually have a shorter detection range, typically less than 30 mm.

How to test a proximity sensor and check whether the output is PNP or NPN?

You can read this article to test your proximity sensor: ¿Cómo probar un sensor de proximidad?.

To know whether your proximity sensor is PNP or NPN is easy, you can connect the positive of 24 VDC power supply to the brown wire, the negative to the blue wire, then use a multi-meter to see the output voltage of the black wire, if it is 24VDC, it is a PNP sensor, if it is 0V, it is a NPN sensor.

¿Todavía tiene preguntas?
